Raxmek ESA875W/Delem DA66T 58T CNC Hydraulic Press Brake – High Precision Metal Bending Machine
SKU: 1601558393476
Technical Specifications
CNC BACKGAUGE
RAXMEK press brakes are equipped with a solid CNC backgauge structure to ensure repeatability and high positioning accuracy across axes.
| BGA | X | R | Z1 | Z2 | X2 |
|---|---|---|---|---|---|
| Stroke mm | 750 | 150 | UNDER REQUEST | UNDER REQUEST | 190 |
| Speed mm/s | 500 | 170 | 2000 | 2000 | 200 |
| Precision mm | +0,02 | +0,05 | +0,05 | +0,05 | +0,02 |
| Type of motor | BRUSHLESS | BRUSHLESS | BRUSHLESS | BRUSHLESS | BRUSHLESS |
| Mechanical system | SCREW | SCREW | RACK | RACK | SCREW |
WILA NEW STANDARD CROWNING AND HOLDERS
WILA crowning systems compensate for deflection in press brakes, ensuring consistent bending angles across the machine's length. These systems use patented adjustable wedges known as Wila Waves.
LASER CHECK ANGLE MEASUREMENT
Laser Check, manufactured by Data M Engineering, is a bend angle measurement and correction system utilizing a laser beam. The device consists of a laser and a camera positioned on both sides of the bending line for detection.
